Measuring length 50 mm... 3000 mm
Dead/blind area 42 mm / 74 mm
Resolution 0.01mm; 0.05mm; 0.1mm; 12 bit / 16 bit ( Analog )
Nonlinearity ≤ ± 0.015%FS (min ± 50μm)
Repetition accuracy ≤ ± 0.005% FS (min ± 10 μm)
Lag ± 0.1mm
Temperature coefficient < 8 μm / °C ≤ 500 mm; < 15 ppm / °C > 500 mm
Material Aluminum extruded profile
Fixing clamp G2; Unlimited installation position (large spacing of fixing clip 500 mm)
Magnetic block T1S3818; T1S5520
